【ZX-C40H】
Black Light PTZ Camera

ZX‑C40H black‑light PTZ camera adopts 1/2.8'' 3MP CMOS sensor with H.264 encoding. It supports smart, full‑color and infrared night‑vision modes and two‑way audio. Featuring human, motion and sound detection, it sends instant mobile alarm push. It supports up to 256G SD card storage, 12V power supply, dual‑band 2.4G/5G WiFi and Bluetooth pairing. It delivers reliable all‑day monitoring for home and small‑scale security scenarios.

Product Details Specifications Technical Q&A Product Inquiry
3MP High‑Definition Black‑Light Image Sensor

ZX‑C40H is equipped with 1/2.8'' 3MP CMOS black‑light sensor and applies H.264 video encoding. It captures sharp 3‑megapixel surveillance footage while optimizing video file size for efficient storage. The black‑light sensor improves low‑light performance significantly, retaining rich details and true‑to‑life colors in dim surroundings. Whether for real‑time remote preview or historical video playback, it provides clear visual evidence for household and small‑site security monitoring requirements.

3MP High‑Definition Black‑Light Image Sensor
Multi‑Mode Dual‑Light Night Vision

Built‑in dual‑light design supports three switchable modes: smart mode, full‑color mode and infrared night‑vision mode. White fill lights produce vivid full‑color night images, while infrared lights deliver clear black‑and‑white footage in complete darkness. Smart mode automatically switches light sources according to ambient brightness. No extra auxiliary lighting equipment is needed. It realizes stable round‑the‑clock monitoring and adapts to porches, yards and other low‑light monitoring locations.

Multi‑Mode Dual‑Light Night Vision
AI Multi‑Detection & Instant Mobile Alarm Push

This PTZ camera integrates human detection, motion detection and sound detection functions. Once human movement, object motion or abnormal noise is detected, it immediately triggers alarm notifications and pushes alerts to your mobile APP. You can get risk reminders without keeping live streaming open. Human‑target filtering helps reduce false alarms. Whether you are working or travelling remotely, you can perceive abnormal events timely and take action to enhance property security.

AI Multi‑Detection & Instant Mobile Alarm Push
Two‑Way Audio & Large‑Capacity Local Storage

Integrated microphone and speaker realize real‑time two‑way audio intercom. You can remotely talk with on‑site personnel, soothe pets or warn unwelcome visitors. For video storage, ZX‑C40H supports SD card up to 256G for local recording. You can conveniently review surveillance records via mobile APP. Powered by stable 12V DC input, it supports long‑term continuous operation, suitable for stable deployment in various indoor and outdoor monitoring environments.

Two‑Way Audio & Large‑Capacity Local Storage
Dual‑Band WiFi & Bluetooth Fast Network Configuration

Supporting both 2.4G and 5G dual‑band WiFi, ZX‑C40H establishes smooth and stable wireless network connection. Bluetooth‑assisted pairing greatly simplifies device activation. Complicated manual WiFi entry steps are eliminated; you can complete network configuration quickly through mobile APP. 12V power supply guarantees consistent power input. It brings simple installation and dependable wireless performance for home, villa and small commercial surveillance projects.

Dual‑Band WiFi & Bluetooth Fast Network Configuration

  • Product Model:ZX-C40H
  • Image Sensor:1/2.8" 3MP CMOS
  • Effective Pixels:2560(H) x 1440(V)
  • Video pixels:1440p
  • Shutter:1/15~1/10,000s
  • Min. Illumination:Color 1Lux@F2.0,Black/White 0.01Lux@F2.0
  • Day/Night:Auto(ICR)/Color/B&W
  • Lens&FOV(H/V/D):2.8mm@F2.0, 100°/ 55°/120°
  • LED:-
  • Pan and tilt:Pan: 0° to 355°, Tilt: 0° to 160°
  • SoC:FH8626V200
  • Bluetooth Module chip:BL-M6355CU1/AIC8800D40L
  • WiFi chip:SV6355/AIC8800D40L
  • APP:Tuya Smart/Smart Life
  • Firmware version:V1.0.0
  • Compression:H.264
  • Bit Rate:32Kbps~2Mbps
  • Frame Rate:15fps
  • Dual Stream:Yes
  • Audio Input/Output:Built-in mic/speaker
  • Audio:Two way
  • Storage:SD card(Max 256GB), Cloud storage
What night‑vision modes are available for ZX‑C40H black‑light PTZ camera?
It offers three optional night‑vision modes: smart mode, full‑color mode and infrared night‑vision mode. Smart mode auto‑switches fill lights based on ambient light. Full‑color mode outputs colored night footage, and infrared mode provides clear black‑white images under dark conditions.
What storage and network options does ZX‑C40H support?
It supports local SD‑card storage with maximum capacity of 256GB. For network connection, it is compatible with 2.4G and 5G dual‑band WiFi, and supports Bluetooth‑aided quick pairing. The camera adopts 12V DC power supply, and power adapter is included within package.
*
*
*
*
*
*
*
